Conductive Tape (Copper Foil Conductive Tape)

Material

Not specified

Applicable Industries

Automotive Industry Electronics & Technology Construction & Architecture Medical & Healthcare

Product Thickness

Standard thickness

Adhesive Type

Acrylic Glue

Shipping Options

Jumbo Roll Semi-finished Roll Die Cut

Product Description

Technical Specifications & Customization Options

  • Substrate: Electrolytic copper foil / Rolled copper foil
  • Adhesive: Conductive acrylic pressure-sensitive adhesive
  • Foil Thickness: Standard 18μm, 25μm, 35μm; custom thicknesses available (range: 18μm–50μm)
  • Total Thickness: 0.05mm–0.10mm
  • Available Widths: Standard 5mm–500mm; customizable slit widths per client requirements
  • Roll Length: Standard 50m/roll, 100m/roll; custom lengths available upon request
  • Release Liner: Single or double release paper, supporting precise die-cutting and automated assembly
  • Supply Format: Jumbo rolls, slit rolls, die-cut pieces (custom dimensions supported)
  • Electrical Performance: Surface resistance ≤0.05Ω; excellent EMI shielding properties
  • Temperature Resistance: -10℃ ~ +120℃
  • Oxidation Resistance: Optional single/double-sided anti-oxidation coating

Target Industries & Applications

  • Internal EMI/EMC Shielding for Electronics (e.g., smartphones, tablets, laptops)
  • Precision Instrument Grounding
  • FPC/PCB Board Electrical Connections
  • EMC Management in New Energy Vehicle Batteries and High-Frequency Components
  • Medical Device RF Interference Suppression
  • Smart Home Devices Electromagnetic Interference Mitigation

Customer Challenges & Our Solutions

Industry Pain Points

  • Compact device interiors demand highly efficient, space-saving shielding materials to prevent signal interference
  • Consistent, long-term electrical conductivity needed with tape suitable for automated production and assembly

Our Solution

  • Ultra-low contact resistance for outstanding shielding, boosting overall device EMC performance
  • Flexible and conformable, enabling easy application on curved or complex structures
  • Supports mass customization—slitting, die-cutting, and tailored solutions compatible with automated assembly lines




Customization & Engineering Collaboration Advantages

  • One-stop supply from jumbo to slit roll to precision die-cuts
  • Expert technical team available for client-side design collaboration, material selection, and structural optimization
  • Proven track record delivering custom shielding and conductive solutions for world-leading automotive electronics, consumer electronics, and medical device manufacturers
